Dimensions:
Small:
- Overall: 60 in W x 15.25 in H
- Blade Pitch: 14 degrees
- Ceiling to Blade Height: 13.5 in
- Motor: 165x25
- Canopy: 6 in Dia
- Wire Length: 76 in
Energy Information:
- RPM (Low - High): 119 - 185
- Airflow measure in cubic feet per minute at High - Low speed (CFM): 8752 - 6079
- Watts at high speed: 32.4
- Airflow efficiency high (CFM/Watts): 298
Large:
- Overall: 80 in W x 15.25 in H
- Blade Pitch: 14 degrees
- Ceiling to Blade Height: 13.5 in
- Motor: 165x25
- Canopy: 6 in Dia
- Wire Length: 76 in
Energy Information:
- RPM (Low - High): 83 - 115
- Airflow measure in cubic feet per minute at High - Low speed (CFM): 11023 - 8548
- Watts at high speed: 33.1
- Airflow efficiency high (CFM/Watts): 439
Lamp Type:
- LED
Bulbs:
- 16W max 120V 1500 Lumens, 90CRI, 3000K LED lamp (included)
Listing:
- ETL
- Damp Rated
Packaged Dimensions:
- Small: 46 in W x 16.4 in D x 15.25 in H
- Large: 44.5 in W x 15.75 in D x 11.4 in H
Product Weight:
- Small: 17.2 lbs.
- Large: 19.18 lbs.
Packaged Weight:
- Small: 24.43 lbs.
- Large: 20.29 lbs.
Product URL
item #:
![](http://www.2modern.com/cdn/shop/files/hinkley-sculpt-led-ceiling-fan_1024x.jpg?v=1728288043)
Prepared for:
Project:
Room:
Placement:
Approval:
- Shipping Cost: Free Shipping
-
Shipping Time: Please make a selection.
- Shop with Confidence: 30 Day Returns
- # SKU: Make a selection
- Quick Ship
- Damp Rated
- LED Compatible
- Energy Efficient
Description
Sculpt defines modern elegance. Its Solid Wood blades are complemented by a clean etched opal glass, seamlessly adding the adequate amount of contemporary character. Sculpt features solid wood blades and is available in Matte Black with Walnut blades or Graphite with Driftwood blades. Sculpt is DAMP rated, making it perfect for both interior and outdoor settings.
Features
- Sculpt Collection
- Install sloped ceiling up to 20 degrees
- 3 blades
- Fan Control included, 6 Speed HIRO: Reversing 980014FWH-R
- Wifi Control Included
- Controllers/Receiver Included: CNW903660 (for Small size), CNW903680 (for Large size)
- Motor Type: DC
- Single circuit required
- Dimmable with CL Type Dimmer (SSL7A)
- ETL Listed
- Damp rated for bathrooms and covered patios
- Title 24
- Available in Graphite / Driftwood OR Matte Black / Walnut finish/blade with Etched Opal glass
- Available in two sizes
Current selected SKU:
Other available SKUs: 903680FGT-LDD, 903660FMB-LDD, 903680FMB-LDD
"Hinkley Sculpt LED Ceiling Fan" (Stock ID 6606822211629)
Have a question about this product? Need help finding something? Our expert Customer Service team is here to help. Give us a call at (888) 222-4410 or email us.
![Sculpt LED Ceiling Fan](http://www.2modern.com/cdn/shop/files/hinkley-sculpt-led-ceiling-fan-view-add11_590x590.jpg?v=1708325677)
Dimensions:
Small:
- Overall: 60 in W x 15.25 in H
- Blade Pitch: 14 degrees
- Ceiling to Blade Height: 13.5 in
- Motor: 165x25
- Canopy: 6 in Dia
- Wire Length: 76 in
Energy Information:
- RPM (Low - High): 119 - 185
- Airflow measure in cubic feet per minute at High - Low speed (CFM): 8752 - 6079
- Watts at high speed: 32.4
- Airflow efficiency high (CFM/Watts): 298
Large:
- Overall: 80 in W x 15.25 in H
- Blade Pitch: 14 degrees
- Ceiling to Blade Height: 13.5 in
- Motor: 165x25
- Canopy: 6 in Dia
- Wire Length: 76 in
Energy Information:
- RPM (Low - High): 83 - 115
- Airflow measure in cubic feet per minute at High - Low speed (CFM): 11023 - 8548
- Watts at high speed: 33.1
- Airflow efficiency high (CFM/Watts): 439
Lamp Type:
- LED
Bulbs:
- 16W max 120V 1500 Lumens, 90CRI, 3000K LED lamp (included)
Listing:
- ETL
- Damp Rated
Packaged Dimensions:
- Small: 46 in W x 16.4 in D x 15.25 in H
- Large: 44.5 in W x 15.75 in D x 11.4 in H
Product Weight:
- Small: 17.2 lbs.
- Large: 19.18 lbs.
Packaged Weight:
- Small: 24.43 lbs.
- Large: 20.29 lbs.
Steel, wood blade, glass.
